DVB IP-Gateways
IGS-924A
24 Transponder DVB to IPTV Gateway
This 24-transponder DVB-to-IP gateway consolidates satellite, cable and terrestrial reception into a single rack unit, streaming up to 128 SPTS reliably into your IPTV network.
Overview
The VIZOBOX IGS-924A is a DVB-to-IP gateway that receives up to 24 satellite, cable or terrestrial transponders and streams them as SPTS/MPTS over IP for IPTV distribution. Through its two GbE ports the unit delivers up to 128 SPTS via UDP and RTP/RTSP as unicast or multicast, at up to 850 Mbps per port. Extensive demultiplexing and stream-processing functions — accurate PCR restamping, PID filtering and re-mapping, PSI/SI rebuilding, CA filter and optional BISS descrambling — are integrated in a single 1RU chassis. DiSEqC support for up to four satellite positions, dual ASI inputs and outputs, USB TS record/playback and web interface management complete the system.
Highlights
- 24 tuner inputs DVB-S/S2/S2X, optionally configurable as multi-mode tuners for DVB-C, DVB-T/T2 and ISDB-Tb
- 128 SPTS IP output over UDP and RTP/RTSP via 2x GbE ports, up to 850 Mbps each (unicast and multicast)
- Comprehensive TS processing: accurate PCR restamping, PID filtering and re-mapping, PSI/SI rebuilding and editing, null-packet filter and CA filter
- BISS descrambling Mode 1 / Mode E (optional) and DiSEqC support for up to 4 satellite positions
- 2x ASI inputs and 2x ASI outputs plus IP stream input, with USB TS record/playback for info-channel streaming
- 2026 redesign (A version): RF loop-through, front LCD with keypad and convenient web interface management
Technical Specifications
| Input | |
|---|---|
| Inputs | 24 tuner inputs + 2x ASI in, IP stream input, TS Recorder/Player -> SPTS output, RF loops |
| Tuner Section — DVB-S | |
| Frequency In | 950...2150 MHz |
| Symbol rate | 0.5...45 Msps |
| FEC | 1/2, 2/3, 3/4, 5/6, 7/8 |
| Constellation | QPSK |
| Tuner Section — DVB-S2 | |
| Frequency In | 950...2150 MHz |
| Symbol rate | QPSK/8PSK/16APSK: 0.5...45 Msps; 32APSK: 0.5...34 Msps |
| FEC | QPSK: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10; 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10; 16APSK: 2/3, 3/4, 4/5, 5/6, 8/9, 9/10; 32APSK: 3/4, 4/5, 5/6, 8/9, 9/10 |
| Constellation | QPSK, 8PSK, 16APSK, 32APSK |
| Tuner Section — DVB-S2X | |
| Frequency In | 950...2150 MHz |
| Symbol rate | QPSK/8PSK/16APSK: 0.5...45 Msps; 8APSK: 0.5...40 Msps; 32APSK: 0.5...34 Msps |
| FEC | QPSK: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10, 13/45, 9/20, 11/20; 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10; 8APSK: 5/9-L, 26/45-L; 16APSK: 2/3, 3/4, 4/5, 5/6, 8/9, 9/10, 1/2-L, 8/15-L, 5/9-L, 26/45, 3/5, 3/5-L, 28/45, 23/36, 2/3-L, 25/36, 13/18, 7/9, 77/90; 32APSK: 3/4, 4/5, 5/6, 8/9, 9/10, 2/3-L, 32/45, 11/15, 7/9 |
| Constellation | QPSK, 8PSK, 8APSK, 16APSK, 32APSK |
| Tuner Section — Satellite | |
| Signal strength | -65...-25 dBm |
| Max input bitrate | <= 125 Mbps |
| Tuner Section — DVB-C (option) | |
| Standard | J.83A (DVB-C), J.83B, J.83C |
| Constellation | 16/32/64/128/256 QAM |
| Frequency In | 60...890 MHz |
| Tuner Section — DVB-T/T2 (option) | |
| Frequency In | 60...890 MHz |
| Bandwidth | 6/7/8 MHz |
| Tuner Section — ISDB-T/ATSC (option) | |
| Frequency In | 60...890 MHz |
| Descrambling | |
| BISS | Mode 1, Mode E (descrambling of individual programs) |
| Output | |
| IP output | 128 SPTS unicast/multicast over UDP and RTP/RTSP via GE1 & GE2 (independent IP address and port), up to 850 Mbps each |
| ASI output | 2x ASI out (selectable SPTS) |
| USB | TS Recorder/Player — TS-file streamer from connected USB pen drive/SSD |
| Management | |
| Control | WEB-IF management, front LCD/keypad; DiSEqC support for up to 4 satellite positions |
